Technical data
Technical Data
- Construction
-
- Standard Single Chamber
- Connection Orientation
-
- Top Mounted
- Chamber top
-
- Welded end cap
- Process Connection
-
- 4” 150# Flanged
- Temperature
-
- -20 to 300 °C
- Pressure
-
- 0 to 3 Kg/cm²
- Material of Construction
-
-
Chamber / Flanges : 316 Stainless Steel
Rail & window : Aluminum rail with glass window
Float : 316 Stainless Steel
-
Chamber / Flanges : 316 Stainless Steel
