Technical data
Technical Data
- Construction
-
- Glass tube with C channel protection
- Connection Orientation
-
- Side / Side
- Integral Isolation Valve
-
- Straight pattern bar stock body
- C-C distance
-
- 350 to 3000 mm
- Visible length
-
- 100-150 mm less than C-C
- Temperature
-
- 200 °C
- Test Pressure
-
- 10 Kg/cm²
- Material of Construction
-
-
Wetted Parts : CS, SS
C channel : MS, SS
Seal ring : PTFE
-
Wetted Parts : CS, SS
