Technical data
Housing
- Nominal size
-
- 100 mm
- Case materia
-
- Die Cast Aluminum
- Bezel ring material
-
- Die Cast Aluminum
- Window material
-
- Acrylic
- Protection rating
-
- IP67
- Dial
-
- White, Aluminium
- Pointer
-
- Grey and red, Aluminium
- Zero Adjustment
-
- External adjusting by means of screw
- Mounting position
-
- Vertical
Temperature
- Ambient temperature
-
- -7 to 60°C
Wetted parts
- Process connection material
-
- Aluminum
- Diaphragm
-
- Silicone
Accessories
- Accessories
-
- Two 1/8” NPT Plugs for duplicate pressure taps, Two 1/8” Pipe thread to rubber tubing adaptor and three flush mounting adaptors with screws
Performance
- Accuracy
-
- (±2.0% of full scale and ±4.0% for ranges 10 mmWC and below)
- Pressure Limit
-
- -0.67 to 1 bar
- Over Pressure
-
- Suitable up to 25 psig
Weight
- Process connection
-
- 1/8” NPT (F) high and low pressure taps,one pair side and one pair back
- Weight
-
- 510 gms (Approx.)
