Technical data
Housing
- Nominal size
-
- 150 mm
- Case materia
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Bezel ring material
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Window material
-
- Shatterproof / safety glass
- (Optional) Toughened glass
- Gasket & filling plug
-
- Neoprene
- Protection rating (IS/IEC 60529)
-
- IP65
- Dial
-
- White, Aluminium
- Pointer
-
- Black, Aluminium
- Movement material
-
- Stainless steel AISI 304 SS
- Safety
-
- Pressure gauge with blow-out device in Neoprene
Temperature
- Ambient temperature
-
- -25°C ... +65°C
- Media temperature
-
- Max +100°C (not filled)
- Max +65°C (Glycerine filled)
Wetted parts
- Process connection material
-
- Stainless steel AISI 316L
- Stainless steel AISI 316L
- Bourdon tube
-
- Stainless steel AISI 316L
Performance
- Accuracy according to EN 837-1
-
- Class 2.5 (Ascending order)
- Min. measuring range
-
- 0 ... 400 mbar
- Max. measuring range
-
- 0 ... 6 bar
- Static pressure
-
- 6 bar up to ranges 600 mbar
- 25 bar for ranges 1bar to 2.5 bar
- 40 bar for ranges 4 bar to 6 bar
- Thermal drift (reference: +20 °C)
-
- ± 0.8 % FS/10K
Weight
- Bottom connection
-
- 2000 g unfilled
