Technical data
Housing
- Nominal size :
-
- 100 mm
- Case material :
-
- Stainless steel AISI 304
- Body:
-
- Stainless steel AISI 316
Aluminium & Monel (Optional)
- Stainless steel AISI 316
- Window material :
-
- Plexi Glass
- Protection rating (IS/IEC 60529):
-
- IP65
- Dial:
-
- Aluminum, black Colored, Fixed
- Pointer :
-
- Black, Aluminum
Temperature
- Ambient temperature
-
- Max 65°C
- Media temperature
-
- Max 80°C
Wetted parts
- Material
-
- Teflon, Ceramic Magnet & SS Spring
Performance
- Accuracy
-
- Class 2 (For ascending order)
- Min. measuring range
-
- 0 ... 1 bar
- Max. measuring range
-
- 0 ... 10 bar
- Type of pressure
-
- Gauge
- Gauge
- Over pressure limit
-
- Up to the Full Scale Value
- Thermal drift (reference: +20 °C)
-
- ± 0.4 % FS/10K
- Static
-
- 10 bar up to ranges 4 bar
- 16 bar for ranges above 4 bar
Weight
- Bottom connection
-
- 460 g unfilled
