Technical data
Housing
- Nominal size
- 100 mm
- Case material
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Bezel ring material
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Window material
-
- Sheet glass
(Optional) Shatterproof/safety glass / Toughened glass
- Sheet glass
- Gasket & Vent plug
-
- Neoprene & EPDM
- Protection rating (IS/IEC 60529)
- IP65
- Dial
- White, Aluminium
- Pointer
- Black, Aluminium
- Movement material
- Stainless steel AISI 304 SS
Temperature
- Ambient temperature
-
- -25°C ... +65°C
- Media temperature
-
- Max +150°C
Wetted parts
- Process connection material
-
- Stainless steel AISI 316L
- Capsule
-
- Stainless steel AISI 316 / 316L
Performance
- Accuracy according to EN 837-1
- Class 1.6
- Min. measuring range
- 0 ... 25 mbar
- Max. measuring range
- 0 ... 600 mbar
- Type of pressure
- Gauge
Compound
Vacuum - Over pressure limit
-
- 130% OF Max. Scale value
- Zero adjustment
-
- Adjustment screw accessible on the front side after
removing of bezel ring and window
- Adjustment screw accessible on the front side after
- Thermal drift (reference: +20 °C)
- ± 0.6 % FS/10K
Weight
- Bottom connection
- 605 g unfilled
