Technical data
Housing
- Nominal size
- 63 mm
- Case material
- Stainless steel AISI 304
- Bezel ring material
- Stainless steel AISI 304
- Window material
-
- Sheet glass
- (Optional) Shatterproof / safety glass / Toughened glass
- Gasket & Vent plug
-
- Neoprene
- Nitrile
- Protection rating (IS/IEC 60529)
- IP55
- Dial
- White, Aluminium
- Pointer
- Black, Aluminium
- Movement material
- Copper alloy
Temperature
- Ambient temperature
- -25°C ... +65°C
- Media temperature
- Max +100°C
Wetted parts
- Process connection material
- Copper alloy
- Capsule
- Copper alloy
Performance
- Accuracy according to EN 837-3
- Class 1.6
- Min. measuring range
- 0 ... 25 mbar
- Max. measuring range
- 0 ... 600 mbar
- Type of pressure
-
- Gauge
Compound
Vacuum
- Gauge
- Over pressure limit
-
- Steady: 75% of full scale value
- Short time: 100% of full scale value
- Thermal drift (reference: +20 °C)
- ± 0.6 % FS/10K
Weight
- Bottom connection
- 255 g unfilled
