Technical data
Housing
- Nominal size
-
- 100 mm
- Case materia
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Bezel ring material
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Window material
-
- Sheet glass
- (Optional) Shatterproof/safety glass / Toughened glass
- Gasket
-
- Neoprene
- Protection rating (IS/IEC 60529)
-
- IP65
- Dial
-
- White, Aluminium
- Pointer
-
- Black, Aluminium
- Movement material
-
- Stainless steel AISI 304 SS
- Stainless steel AISI 316 SS (Optional)
Temperature
- Ambient temperature
-
- -25°C ... +65°C
- Media temperature
-
- Max +100°C
Wetted parts
- Process connection material
-
- Stainless steel AISI 316L
- (Optional) Monel / Hastelloy C / Titanium / PP / PVC / PVDF
- Diaphragm
-
- Stainless steel AISI 316
- (Optional) Monel / Hastelloy C
Performance
- Accuracy according to EN 837-1
-
- Class 1.6
- Min. measuring range
-
- 0 ... 25 mbar
- Max. measuring range
-
- 0 ... 10 bar
- Type of pressure
-
- Gauge
Compound
Vacuum
- Gauge
- Over pressure limit
-
- Steady: 75 % of full scale value
- Short time: 125 % of full scale value
- Thermal drift (reference: +20 °C)
-
- ± 0.4 % FS/10K
Weight
- Bottom connection
-
- 2600 g (Low pressure, threaded connection)
- 1560 g (High pressure, threaded connection)
