Technical data
Housing
- Nominal size
-
- 63 mm
- Case materia
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Bezel ring material
-
- Stainless steel AISI 304
- Stainless steel AISI 316 (Optional)
- Window material
-
- Plexi glass
- (Optional) Shatterproof / safety glass / Toughened glass for bayonet design
- Gasket & filling plug
-
- Silicon rubber & Nitrile
- Protection rating (IS/IEC 60529)
-
- IP65
- Dial
-
- White, Aluminium
- Pointer
-
- Black, Aluminium
- Movement material
-
- Stainless steel AISI 304 SS
Temperature
- Ambient temperature
-
- -10°C ... +65°C
- Media temperature
-
- -10°C ... +180°C (not filled)
- Max +65°C (Glycerine filled)
Wetted parts
- Process connection material
-
- Stainless steel AISI 316L
- Diaphragm
-
- Stainless steel AISI 316L
Performance
- Accuracy according to EN 837-1
-
- Class 1.6
- Min. measuring range
-
- 0 ... 2 bar
- Max. measuring range
-
- 0 ... 40 bar
- Type of pressure
-
- Gauge
Compound
Vacuum
- Gauge
- Over pressure limit
-
- 130 % of Max. scale value
- Sealing fluid
-
- Food Grade Oil (OKS 370)
- Thermal drift (reference: +20 °C)
-
- ± 0.4 % FS/10K
Weight
- Bottom connection
-
- 350 g (1 ½” TC connection)
