Technical data
Housing
- Nominal size :
-
- 150 mm
- Case material :
-
- AISI 304 SS
- Bezel ring material :
-
- AISI 304 SS
- Window material :
-
- Shatterproof / Safety Glass
- Gasket & ‘O’ ring :
-
- Neoprene
- Protection rating (IS/IEC 60529) :
-
- IP65
- Dial:
-
- White, Aluminum
- Pointer :
-
- Black, Aluminum
- Movement material :
-
- Stainless steel AISI 304 SS
Temperature
- Ambient temperature
-
- - 25°C to + 65°C
- Media temperature
-
- -25 to 80°C
Performance
- Accuracy
-
- Class 1
- Min. measuring range
-
- -1/0 ... -1/24 bar
- Max. measuring range
-
- 0 ...200 bar
- Type of pressure
-
- Gauge
Compound
Vacuum
- Gauge
- Over pressure limit
-
- Up to the Full Scale Value
- Electrical connections
-
- DIN connector
- Power supply
-
- 24 VDC
- Output
-
- 4 – 20 mA
- System
-
- 2 wire
Weight
- Bottom connection
-
- 1450 g unfilled
