Technical data
Housing
- Nominal size
- 150 mm
- Case material
- Stainless steel AISI 304
- Bezel ring material
- Stainless steel AISI 304
- Window material
- Shatterproof / safety glass
- Gasket
- Neoprene
- Protection rating (IS/IEC 60529)
- IP65
- Dial
-
- Aluminium, Green with black marking & Anti Parallax Mirro band
- Pointer
-
- Aluminium, Black Knife-Edge Micrometer Adjustable
- Movement material
-
- High Precision Jewel Bearing Type
- Carrying case
-
- Wooden carrying case
- Calibration certificate
-
- Traceable to National / International standard.
Temperature
- Ambient temperature
-
- -25°C ... +65°C
Wetted parts
- Process connection material
-
- Stainless steel AISI 316L
- Bourdon tube
-
- Beryllium Copper
Performance
- Accuracy according to EN 837-1
- Class 0.25
- Min. measuring range
- 0 ... 0.6 bar
- Max. measuring range
- 0 ... 1600 bar
- Type of pressure
- Gauge
Vacuum - Over pressure limit
-
- Steady: 75 % of full scale value
- Fluctuating: 60 % of full scale value
- Short time: 100 % of full scale value
- Thermal drift (reference: +20 °C)
- ± 0.4 % FS/10K
Weight
- Bottom connection
- 2180 g unfilled
