Technical data
Housing
- Nominal size
-
- 150 mm
- Case materia
-
- Stainless steel AISI 304
- Bezel ring material
-
- Stainless steel AISI 304
- Window material
-
- Shatterproof / safety glass
- Gasket & filling plug
-
- Neoprene
- Protection rating (IS/IEC 60529)
-
- IP65
- Dial
-
- Aluminium, Green with black marking & Anti Parallax Mirro band
- Pointer
-
- Aluminium, Black Knife-Edge Micrometer Adjustable
- Movement material
-
- High Precision Jewel Bearing Type
- Carrying case
-
- Wooden carrying case
- Calibration certificate
-
- Traceable to National / International standard.
Temperature
- Ambient temperature
-
- Maximum +65°C
- Process temperature
-
- Maximum +65°C
Wetted parts
- Process connection material
-
- Stainless steel AISI 316L
- Bourdon tube
-
- Beryllium Copper
Performance
- Accuracy according to EN 837-1
-
- Class 0.25
- Min. measuring range
-
- 0 ... 0.6 bar
- Max. measuring range
-
- 0 ... 1000 bar
- Type of pressure
-
- Gauge
Vacuum
- Gauge
- Over pressure limit
-
- Steady: 75 % of full scale value
- Short time: 100 % of full scale value
- Thermal drift (reference: +20 °C)
-
- ± 0.4 % FS/10K
Weight
- Bottom connection
-
- 1100 g unfilled
