Technical data
Housing
- Nominal size
-
- 40 mm
- Case material
-
- Steel, Powder coated / painted
- Bezel ring material
-
- Steel, Powder coated / painted (Push fit type)
- Window material
-
- Sheet glass
- Dial
-
- White, Aluminium
- Pointer
-
- Black, Aluminium
- Movement material
-
- Copper alloy
Temperature
- Ambient temperature
-
- -25°C ... +65°C
- Media temperature
-
- Max +150°C
Wetted parts
- Process connection material
-
- Copper alloy
- Bourdon tube
-
- Copper alloy
Performance
- Accuracy according to EN 837-1
- Class 2.5
- Min. measuring range
- 0 ... 1 bar
- Max. measuring range
- 0 ... 250 bar
- Type of pressure
- Gauge
Vacuum - Over pressure limit
-
- ≤ 100 bar : 125 % of Max. scale value
- > 100 to ≤ 600 bar : 115 % of Max. scale value
- > 600 to ≤ 1600 bar : 110 % of Max. scale value
- Thermal drift (reference: +20 °C)
- ± 0.4 % FS/10K
Weight
- Bottom connection
-
- 82 g
