Technical data
Housing
- Nominal size
-
- 50 mm
- Case material
-
- Steel, Powder coated / painted
- Bezel
-
- Snap-in glass
- Window material
-
- Polycarbonate glass
- Dial
-
- White
- Aluminium
- Pointer
-
- Black
- Aluminium
- Movement material
-
- Copper alloy
Temperature
- Ambient temperature
-
- -25°C ... +65°C
- Media temperature
-
- Max +65°C
Wetted parts
- Process connection material
-
- Copper alloy
- Bourdon tube
-
- Copper alloy
Performance
- Accuracy according to EN 837-1
- Class 2.5
- Min. measuring range
- 0 ... 2.5 bar
- Max. measuring range
- 0 ... 400 bar
- Type of pressure
- Gauge
- Over pressure limit
-
- ≤ 100 bar : 125 % of Max. scale value
- > 100 to ≤ 600 bar : 115 % of Max. scale value
- > 600 to ≤ 1600 bar : 110 % of Max. scale value
- Thermal drift (reference: +20 °C)
- ± 0.4 % FS/10K
Weight
- Bottom connection
- 105 g
