Technical data
Housing
- Nominal size
- 100 mm
- Case material
-
- Stainless Steel AISI 304
- Bezel ring material
-
- Stainless steel AISI 304
- Window material
-
- Plexi glass
- Gasket & Filling plug
-
- Neoprene
- Protection rating (IS/IEC 60529)
- IP65
- Dial
- White, Aluminium
- Pointer
- Black, Aluminium
- Movement material
- Copper alloy
Temperature
- Ambient temperature
-
- -25°C ... +65°C
- Media temperature
-
- Max +150°C
Wetted parts
- Process connection material
-
- Copper alloy
- Bourdon tube
-
- Copper alloy up to 70 bar & AISI 316L for 100 bar & above
Performance
- Accuracy according to EN 837-1
- Class 1.6
- Min. measuring range
- 0 ... 1 bar
- Max. measuring range
- 0 ... 400 bar
- Type of pressure
- Gauge
Compound
Vacuum - Over pressure limit
-
- ≤ 100 bar : 125 % of Max. scale value
- > 100 to ≤ 600 bar : 115 % of Max. scale value
- Thermal drift (reference: +20 °C)
- ± 0.4 % FS/10K
Weight
- Bottom connection
- 620 g unfilled
