Technical data
Housing
- Protection rating (IS/IEC 60529)
-
- W/P to IP 66
- Enclosure material
-
- Die cast aluminum
- Mounting
-
- Bottom / Panel
- Optional
-
- 2” pipe mounting
Temperature
- Ambient temperature
-
- -10 to 60 °C
- Media temperature
-
- maximum up to 150 °C
Wetted parts
- Process connection material
-
- Stainless steel AISI 304
- Diaphragm
-
- Stainless steel AISI 316L
Performance
- Min. pressure range
-
- -1 to 0 bar
- Max. pressure range
-
- 4 to 40 bar
- Repeatability
-
- ± 1% F. S
Technical Data
- Adjustment
-
- Set point
-
- Between 20 to 80% F.S.
- Differential
-
- Adjustable
- Approval / Conformities
-
- -
