Technical data
Housing
- Protection rating (IS/IEC 60529)
-
- W/P to IP 32
- Enclosure material
-
- Steel (plated) with plastic cover
- Mounting
-
- Bottom / Panel
- Optional
-
- Mounting bracket with screw
Temperature
- Ambient temperature
-
- -10 to 60 °C
- Media temperature
-
- maximum up to 100 °C
Wetted parts
- Process connection material
-
- Phosphor bronze / brass with plating
- Bellows
-
- Phosphor bronze
Performance
- Min. pressure range
-
- 0 to 3 bar
- Max. pressure range
-
- 5 to 30 bar
- Repeatability
-
- ± 2% F. S
Technical Data
- Adjustment
-
- Set point
-
- Between 20 to 80% F.S.
- Differential
-
- Adjustable
- Approval / Conformities
-
- -
