Technical data
Technical Data
-
- Temperature range: –200 to 600 °C (–328 to 1112 °F) according to IEC 60751
- Designs: Freely Suspended, Heat Transfer Block, Spring-loaded, Guiding Tube
- Head mounted transmitter analogue (4-20mA) & communication protocol (HART)
Application
-
- Specifically designed for Oil & Gas and Petrochemical processing industries
- Measuring range: –200 to 600 °C (–328 to 1112 °F)
- Degree of protection up to IP66/67
- Hazardous area classifications: Flameproof Exd-IIA/IIB-T6 & Explosionproof Exd-IIC-T6
Accuracy
-
- Class AA: ± (0.1 + 0.0017 · |t| )
- Class A: ± (0.15 + 0.002 · |t| )
- Class B: ± (0.3 + 0.005 · |t| )
Ambient Conditions
-
- -40 to 85 °C
