Technical data
Temperature
-
- |t| = absolute value °C
Technical Data
-
- Temperature range: –50 to +200 °C (–58 to +392 °F) according to IEC 60751
- Variety of process connections & sheath diameters
- Various process connections Tri-clover Flange, Ingold, SMS
- Head mounted transmitter analogue (4-20mA) & communication protocol (HART)
Application
-
- Universal range of application
- Measuring range: –50 to +200 °C (–58 to +392 °F)
- Degree of protection up to IP68
- Terminal head MOC: Die Cast Aluminum, SS316L
Accuracy
- Class AA:
-
- ± (0.1 + 0.0017 · |t| )
- Class A:
-
- ± (0.15 + 0.002 · |t| )
- Class B:
-
- ± (0.3 + 0.005 · |t| )
Ambient Conditions
- Ambient conditions
-
- -40 to 85 °C
