Technical data
Technical Data
-
- Mineral insulation enables flexibility and durability
- Available in various process connections & sheath diameters
- Enclosures Junction Box Weatherproof IP - 67
- Flameproof Gr. IIA, IIB
- Explosion proof IIA, IIB, IIC
- Designs: Freely Suspended, Heat Transfer Block, Spring-loaded, Guiding Tube
- Head mounted transmitter analogue (4-20mA) & communication protocol (HART)
- Reference standard : IEC 60584.2 / ANSI MC – 96.1 / ASTM E230
Application
-
- Application These assemblies are find application in Refinery and Petrochemical plants which includes catalytic crackers, lime kilns, distillation columns & pressurized reactor vessels.
Accuracy
-
- Class 1 / Class 2 acc. to IEC 60584
- Standard limits of error / special limits of error acc. to ANSI MC – 96.1 / ASTM E230
Ambient Conditions
- Ambient conditions
-
- -40 to 85 °C
