Technical data
Technical Data
-
- Mineral insulated cable.
- Available in various sheath diameters
- Enclosures (Head) Weatherproof IP - 67
- Flameproof Gr. IIA, IIB
- Explosion proof IIA, IIB, IIC
- Transmitter output 4 - 20mA (Optional)
- Reference standard : IEC 60584.2 / ANSI MC – 96.1 / ASTM E230
Application
-
- This design is specifically used to measure skin temperature of heater tube or flat surface Our thermocouple assembly will be with weld pad which will be directly welded on heater tube or flat surface Curvature to weld pad will be provided as required by customer Typical applications are measurement of surface temperature of refractory lined vessels, columns, reactors in petrochemical plants and oil refineries and pipelines.
Accuracy
-
- Class 1 / Class 2 acc. to IEC 60584
- Standard limits of error / special limits of error acc. to ANSI MC – 96.1 / ASTM E230
Ambient Conditions
- Ambient conditions
-
- -40 to 85 °C
