Technical data
Housing
- Protection rating (EN 60529)
-
- IP65
- Dial
-
- Aluminium, black graduation on white background
- Pointer
-
- Aluminium, black Coloured Micrometer Zero adjustable
- Window material
-
- Plexi glass
- Window gasket
-
- Neoprene
- Movement material
-
- SS304
- Nominal size
-
- 100 mm
- Case material
-
- Stainless steel AISI 304
- Bezel ring material
-
- Stainless steel AISI 304
- Joints
-
- Tig Argon arc welding
- Electrical Contacts
-
- CE & ATEX approved electrical contacts.
Standard version
- Accuracy
-
- Class 1 as per EN 13190
- Ambient temperature
-
- -25°C to 65°C
- Operating pressure
-
- 15 kg/cm2 ( without thermowell )
- Over range limit
-
- 120 % of Full Scale
- Stem diameter
-
- 8 mm
- Process connection
-
- 1/2“ BSP (M) Adjustable
- Standard version : Electrical contacts: Accuracy
-
- Class 1 as per EN 13190
- Ambient temperature
-
- Maximum 65°C
- Window
-
- Polycarbonate Dome
- Dampening Liquids
-
- Dielectric Oil (Optional)
- Other Features
-
- Refer Specification of Standard Version
Standard version : Silicon oil filled
- Accuracy
-
- Class 1 as per EN 13190
- Ambient temperature
-
- Maximum 65°C
- Window
-
- Plexi Glass
- Dampening Liquids
-
- Silicon Oil (Option QA)
- Gasket
-
- Viton
- Filling Plug
-
- EPDM
- Other Features
-
- Refer Specification of Standard Version
Temperature
- Temperature range
-
- -80°C ... +600°C
- Over range limit
-
- 120 % FS
Wetted parts
- Immersion tube material
-
- Stainless steel AISI 316
Accessories
- Accessories
-
- Sliding connections and thermowells, see datasheets
- Capillary
-
- Capillary up to 15 Meters
- MOC: AISI 304 / AISI 316 (Coated capillary on request)
- (For other lengths contact sales team)
Weight
- Bottom connection
-
- Approx. 1000 grams #
- (# Weight in grams with box for 300 mm stem length & 3 meter capillary.)
